Electromagnetic induction sealing machine using elecromagnetic induction principle, the aluminum foil placed in the electromagnetic induction device, the use of instantaneous heat generated by the aluminium foil in the sealing, sealing the bottle, play moisture, leak, mildew and other sealing effect and extended storage cycle of the purpose, widely used in medicine, pesticides, lubricants and cosmetics and other areas of product sealing.
Features
- Stainless steel construction for using in harsh environment and easy for clean and maintenance;
- It can work with seals of various materials for bottles or jars;
- Fast speed for bulk production;
- It has stable and reliable performance with long working life;
- Conveyor speed & sealing speed variable;
- Easy to use, no special train on operator required;
- Height of sealing line adjustable to accept wide range of bottle heights;
- Electric current overload, voltage overload and output overload protection;
- Air Cooling System eliminates all water cooling pipes, pumps, filters and flow switche
Advantages
1.The working height can be adjusted according to bottle size.This machine is suitable for 10-300 mm height of the bottles and it can widen the application range.
2.With cooling fans,can dissipate heat effectively, protect the machine from over-loading.
3.This machine is equipped with multiple cooling fans to lose heat,which can make sure the machine work stably during working,prevent from overload after long time work.
4.Integrated circuit make sure the machine work stably.and there have the circuit protection device, this ensures the safety operation.
Applications
This aluminium foil sealing machine can be connected with equipments such as capsule counting machine, capping machine, labeling machine to form a production line, its easy to install at side of conveyor.
Parameter Data
|
Model
|
XFY-2300S
|
|
Rating voltage
|
AC220/110V 50/60Hz
|
|
Max. power
|
2500W
|
|
Sealing diameter
|
Φ15-60mm or Φ50-120mm
|
|
Sealing speed
|
0-150 bottles/min according diameter of bottles
|
|
Cooling method
|
Air cooling
|
|
Applicable for
|
Batch production
|
|
Size of main frame
|
Size of main machine
|
|
Packing size
|
1220×720×480mm, weight 47kg
|
|
Adjustable frame
|
1340×400×300mm, weight 17kg
|
|
Equipment weight
|
64kg
|
|
Appearance
|
Stainless steel
|
