Features :
- Versatile application: Suitable for a wide range of products, including ready-made meals, fruits and vegetables, fresh meat, and seafood.
- Compact footprint: Features a compact design and flexible layout, allowing for easy relocation.
- Compatible with various molds: Rapid mold changes (5 to 10 minutes) support diverse production needs, reducing costs and boosting efficiency.
- Fully electric drive: No compressed air required.
- High packaging efficiency: Dual-station design doubles output.
- User-friendly operation: PLC touchscreen interface with a streamlined layout and clear, real-time status display.
- Two film-feeding modes: Accommodates different film sizes, fixed-length mode and color-mark tracking mode.
- Two sealing options: Meets diverse packaging requirements, wave-pattern sealing and easy-peel sealing.
Parameters :
- Voltage : 220 V / 50 Hz or 110 V / 60 Hz
- Total Power : 2.2 kW
- Sealing Power : 1.2 kW
- Max Film Width : 270 mm
- Max Roll Diameter : 220 mm
- Flush Gas N2 or N2 + CO2
- Housing Material : SUS304
- Packaging Mode : Vacuum MAP
- Packaging Speed : 2-3 cycles/min
- Pump Capacity : 20 m3/h
- Dimensions (L x W x H) : 1025 x 620 x 970 mm
- Net Weight : 160 kg
