Through the relative movement of different geometric shapes of static and static grinding, the material being processed under the action of gas pressure and centrifugal force, by the strong shear, friction, impact, high frequency vibration, vortex and other complex forces, the material is effectively Dispersed, broken, emulsified, homogeneous, evenly mixed, so as to get the ideal fine products.
Features
- Contact with the material are made of stainless steel, corrosion resistance, in harsh environments can be a long time continuous and stable work.
- Static and static grinding, with special treatment, grinding high hardness, high precision, grinding fine, durable long life
- Pump body, adjust the disk, cover, etc. are made of raw steel, high density, no sand holes, more durable.
- The machine uses non-contact bushing seal, with anti-leakage, maintenance-free features.
- Adjust the disc can be adjusted thickness, easy to operate. Standard copper coil motor with long service life
Advantage
- High quality stainless steel, corrosion resistant and non-toxic for food.
- 420 Stainless steel rotor and rotator guarantee long time using life
- Well designed, low noise and stable performance.
- Simple internal structure, easy to clean and maintain.
- Compact structure, reduce transportation cost.
Applications
- Food Industry: liquid and paste emulsifying, liquid-powder mixing, liquid-liquid mixing, meat mixing, meat emulsifying, fruit and vegetable grinding, fruit tea, chocolate refining, soy milk, mung bean milk, rice milk, peanut butter, tahini sesame paste, chili sauce, almond paste, cream mixing, jam, fruit juice, soybean paste, bean paste, liquid spices, dairy products and so on.
- Chemical Industry: paint, pigment, dye, coating, catalyst, asphalt, adhesive, detergent all kinds of syrup, nutrient solution, all kinds of ointment, cod liver oil, royal jelly and so on.
Parameter Data
Model |
JMC-60 Vertical |
Base Housings | Stainless Steel |
Supply | 220V 50Hz |
Power | 1.5 KW |
Rotate Speed | 2800 r/min |
Fineness |
50-120 mesh |
Liquid Output | 100-500 kg/h |
Peanut Butter | 10-25 kg/h |
Hopper | 4.1 L |
Weight | 45 kg |
Machine size (L x W x H) | 28 x 28 x70 cm |
Package Size (L x W x H) | 36 x 36 x 80 cm |
