Features:
- Stability: Adopting industrial-grade weighing module and PLC control system, weighing is stable and accurate.
- Fast speed: Combining gravity feeding and vibration feeding, four weighing buckets measure and discharge alternately.
- High accuracy: Step-type multi-speed feeding, small error.
- Auto Calculation: The system can automatically calculate the fast and slow weight, and correct the error value.
- Stable structure: One weighing bucket corresponds to one vibrator and one weighing sensor, which are independent of each other.
- Simple operation: Equipped with electronic touch screen, weight parameters can be directly input.
- Easy to clean: The surrounding open design, the dust cover can be opened, and the interior is easy to clean.
Working Principle:(Weighing Measurement)
| 0-190g: Fast Filling(Weighing)
Material enters into vibration feeder. Vibration starts fast filling until reaching the “fast weight” |
|
| 190-200g: Slow Filling(Weighing)
Vibration starts slow filling until reaching the “slow weight” |
|
| “190g” “200g” is just an example,the specific setting depends on the situation. |
Parameters:
| Packing Weight | 5g-2KG (Depends on Material) |
| Hopper Volume | 3.5L |
| Hopper QTY | 4 |
| Packing Speed | 1200-3600 bottles/h |
| Packing Accuracy | ≤±0.3% (Depends on Material) |
| Power | AC220V 0.8KW |
| Machine Weight | 200KG |
| Dimensions | L800 × W820 × H2160mm |
