NJP series fully automatic capsule filling machine are newly invented machine, which is produced to meet high production capacity requirement on the basis on original NJP series capsule filling machine. These two machines have dual capsule turn around device, and dual capsule hole moulds. It can increase the production capacity without increase operator and space.
This machine is designed further improved on the base of original full auto. capsule filling machine from home and aboard, with high technology and exclusive performance, it is function can reach international leading lvvel, it is an ideal equipment for capsule and medicine in pharmaceutical industry.
Features
Good-looking appearance, exquisite workmanship, ease of operation, simplicity of use. Stowage seat and measuring plate are designed as one unit to make measuring plate and stowage rod without deviation, Phenomenon avoid friction Phenomenon between stowage rod and measuring plate, improve its precision highly, furthermore, it prolongs the machine’s life greatly.
Ineligible capsule can be eliminated automatically(qualified rate not included), the medicine in the capsule can be recycled and be reused thus it can increase greatly heconimic efficiency.
Simplicity and convenience of dismantling, installation and clean, various models of mould can be replaced each other, the mould of 80 model and 1000model as well as 1200 model can be replace mutually on the same machine to meet different requirement of capacity.
Dust collector and vacuum pipe as well as waste air Pipe are installed in the inner of the machine to avoid the air pipe becoming hard, bard broken and leakage etc phenomenon, it is mo re convenient to clean the platform. Furthermore, it accords with the requirement of GMP that medicine can not contact with organic material.
The cap of stowage rod is made of stainless steel which replaces original plastic cap to void breaking Phenomenon; the screws and caps on the platform lesser to make the whole appearance more good-looking.
Parameters：
| Machine model |
NJP800
|
NJP1000
|
NJP1200
|
NJP2500
|
NJP3800
|
NJP7500
|
| Capacity(capsule/min) |
800
|
1000
|
1200
|
2500
|
3800
|
7500
|
| Quantity of die holes |
6
|
8
|
9
|
18
|
27
|
54
|
| Capsule size |
NO.00-5
|
|||||
| Filling precision |
＞99%
|
|||||
| Electric Power supple |
380V50HZ
|
|||||
| Noise |
＜80dBA
|
|||||
| Vacuum degree |
0.02-0.06Mpa
|
|||||
| Degree of Power(kw) |
5.5kw
|
6.74 kw
|
9.5 kw
|
10.5 kw
|
||
| Overall dimension(mm) |
970×820×1900
|
1150×1040×2230
|
1430×1280×2080
|
1700×1220×2015
|
||
| Weight(kg) |
900kg
|
1400kg
|
2400kg
|
3400kg
|
||
