Suitable for packing of various of granule, slice , stripe , such as potato chips , shrimp chip,peanut. popcorn, seed and sugar, etc. This machine is suitable for packaging granular or small products such as candies, peanuts, pistachios, melon seeds, potato chips, fish balls, etc. to improve production efficiency. Widely used in food, chemical, pharmaceutical and other industries.
Parameters
| Model | DH-420ZHC | DH-520ZHC | DH-620ZHC | DH-720ZHC |
| Max Film Width | 420mm | 520mm | 620mm | 720mm |
| Bag width | 55-200mm | 80-250mm | 100-300mm | 140-350mm |
| Bag length | 40-300mm | 40-350mm | 40-400mm | 40-450mm |
| Packing speed | 15-60bags/min | 15-60bags/min | 10-50bags/min | 10-40bags/min |
| Power | 3.5kw | 3.5kw | 3.8kw | 4kw |
| Meaursing range | Max.1200ml | Max.2500ml | Max.3500ml | Max.4500ml |
| Power supply | 220/380V 50/60Hz | 220/380V 50/60Hz | 220/380V 50/60Hz | 220/380V 50/60Hz |
| Air supply | 0.8Mpa 0.4m³/min |
0.8Mpa 0.45m³/min |
0.8Mpa 0.55m³/min |
0.8Mpa 0.65m³/min |
| Weight | 370kg | 370kg | 490kg | 695kg |
| Main machine size | L1480*W1030*H1310mm | L1570*W1140*H1510mm | L1680*W1250*H1710mm | L1910*W1420*H2000mm |
